Segment usage: Medium Back Pressure, Refrigerants: R404A; R452A, Compressor power supply [V]: 230/1/50
| Gross weight |
21.2 Kilogram |
| Net weight |
20 Kilogram |
| Volume |
59.102 Liter |
| EAN |
5702428565288 |
| Gross weight |
21.2 Kilogram |
| Net weight |
20 Kilogram |
| Volume |
59.102 Liter |
| EAN |
5702428565288 |
| Air flow @ 50Hz [m³/h] |
620 m³/h |
| Applications |
MBP |
| Approval |
CE
EAC |
| CE evaluated |
Yes |
| China RoHS compliance |
Out of scope |
| Compressor model |
FR6DLX |
| Compressor power supply [V] |
230/1/50 |
| Condenser type |
BG_3 |
| Contain batteries |
No |
| Description |
OP-MCHC006FRA04G |
| Electrical code |
G |
| EU RoHS compliance |
Out of scope |
| Family |
Optyma™ |
| Fan blade size [mm] |
230 mm |
| Fan current @ 50Hz [A] |
0.25 A |
| Fan current @ 60Hz [A] |
0.22 A |
| Fan power consumption @ 50Hz [W] |
36 W |
| Fan power consumption @ 60Hz [W] |
34 W |
| Fan power output @ 50Hz [W] |
10 W |
| Fan power output @ 60Hz [W] |
9 W |
| Fan power supply [V/Ph/Hz] |
230/1/50 |
| Fan voltage @ 50Hz (max) [V] [Max] |
240 V |
| Fan voltage @ 50Hz (max) [V] [Min] |
220 V |
| Fan voltage @ 60Hz (max) [V] [Max] |
240 V |
| Fan voltage @ 60Hz (max) [V] [Min] |
220 V |
| Frequency [Hz] |
50 Hz |
| High value of nominal voltage at 60Hz [V] |
240 V |
| Liquid line connection [in] |
1/4 in |
| Low value of voltage range at 60Hz [V] |
220 V |
| Model number |
OP-MCHC006 |
| No. of phases (compressor) |
1 |
| No. of phases (fan) |
1 |
| Number of fans |
1 |
| Phase |
1 |
| Product group |
Condensing Units |
| Product Name Description |
Bare unit |
| REACH Candidate List substances |
No |
| Receiver approval |
UL |
| Refrigerants |
R404A
R452A |
| Segment usage |
Medium Back Pressure |
| Sound power @ 50Hz [db(A)] |
62 dBA |
| Speed Platform |
Fixed-speed |
| Suction connection size [in] |
5/16 in |
| Technology |
Reciprocating |
| Type |
Optyma™ A04 |
| UK RoHS compliance |
Out of scope |
| Version |
A04 |
| Voltage 50Hz [V] |
220 V |
| Voltage 50Hz [V] [Max] |
240 V |
| Air flow @ 50Hz [m³/h] |
620 m³/h |
| Applications |
MBP |
| Approval |
CE
EAC |
| CE evaluated |
Yes |
| China RoHS compliance |
Out of scope |
| Compressor model |
FR6DLX |
| Compressor power supply [V] |
230/1/50 |
| Condenser type |
BG_3 |
| Contain batteries |
No |
| Description |
OP-MCHC006FRA04G |
| Electrical code |
G |
| EU RoHS compliance |
Out of scope |
| Family |
Optyma™ |
| Fan blade size [mm] |
230 mm |
| Fan current @ 50Hz [A] |
0.25 A |
| Fan current @ 60Hz [A] |
0.22 A |
| Fan power consumption @ 50Hz [W] |
36 W |
| Fan power consumption @ 60Hz [W] |
34 W |
| Fan power output @ 50Hz [W] |
10 W |
| Fan power output @ 60Hz [W] |
9 W |
| Fan power supply [V/Ph/Hz] |
230/1/50 |
| Fan voltage @ 50Hz (max) [V] [Max] |
240 V |
| Fan voltage @ 50Hz (max) [V] [Min] |
220 V |
| Fan voltage @ 60Hz (max) [V] [Max] |
240 V |
| Fan voltage @ 60Hz (max) [V] [Min] |
220 V |
| Frequency [Hz] |
50 Hz |
| High value of nominal voltage at 60Hz [V] |
240 V |
| Liquid line connection [in] |
1/4 in |
| Low value of voltage range at 60Hz [V] |
220 V |
| Model number |
OP-MCHC006 |
| No. of phases (compressor) |
1 |
| No. of phases (fan) |
1 |
| Number of fans |
1 |
| Phase |
1 |
| Product group |
Condensing Units |
| Product Name Description |
Bare unit |
| REACH Candidate List substances |
No |
| Receiver approval |
UL |
| Refrigerants |
R404A
R452A |
| Segment usage |
Medium Back Pressure |
| Sound power @ 50Hz [db(A)] |
62 dBA |
| Speed Platform |
Fixed-speed |
| Suction connection size [in] |
5/16 in |
| Technology |
Reciprocating |
| Type |
Optyma™ A04 |
| UK RoHS compliance |
Out of scope |
| Version |
A04 |
| Voltage 50Hz [V] |
220 V |
| Voltage 50Hz [V] [Max] |
240 V |
