| Gross weight | 0.051 Kilogram |
| Net weight | 0.042 Kilogram |
| Volume | 0.12 Liter |
| EAN | 5702420016917 |
| Gross weight | 0.051 Kilogram |
| Net weight | 0.042 Kilogram |
| Volume | 0.12 Liter |
| EAN | 5702420016917 |
| Ambient temperature max. [°C] | 100 °C |
| Ambient temperature max. [°F] | 212 °F |
| Body material | Nickel coated Copper |
| Cable length [in] | 78.74 in |
| Cable length [m] | 2 m |
| Cable tempr. range [°C] [max] | 100 °C |
| Cable tempr. range [°C] [min] | -40 °C |
| Cable type | PVC |
| CE evaluated | Yes |
| China RoHS compliance | Out of scope |
| Contain batteries | No |
| Electrical connection | Cable |
| Electrical connection size | 2 wire |
| Electrical connections terminals | 2-wire cable (2 x 0,2 mm2) |
| Grade of enclosure | IP54 |
| Measuring range [°C] [max] | 100 °C |
| Measuring range [°C] [min] | -50 °C |
| Measuring range [°F] [max] | 212 °F |
| Measuring range [°F] [min] | -58 °F |
| Media temperature [°C] [Max] | 100 °C |
| Media temperature [°C] [Min] | 0 °C |
| Mounting version | Clamp for tube DN 15-65 supplied |
| Packing format | Multi pack |
| Product group | Sensors |
| Product Name Description | Temperature sensor |
| Quantity per packing format | 72 pc |
| REACH Candidate List substances | Lead (CAS no. 7439-92-1) |
| Sensor elem. resistance [Ohm] | 1000 |
| Sensor element [pc] | 1 pc |
| Sensor element standard | EN 60751 |
| Sensor element tolerance | Class B |
| Sensor element type | Pt |
| Temperature sensors type | Pt 1000 |
| Time constant | 10 s |
| Type | ESMC |
| UK RoHS compliance | Out of scope |
| Wires [pcs] | 2 pc |
| Ambient temperature max. [°C] | 100 °C |
| Ambient temperature max. [°F] | 212 °F |
| Body material | Nickel coated Copper |
| Cable length [in] | 78.74 in |
| Cable length [m] | 2 m |
| Cable tempr. range [°C] [max] | 100 °C |
| Cable tempr. range [°C] [min] | -40 °C |
| Cable type | PVC |
| CE evaluated | Yes |
| China RoHS compliance | Out of scope |
| Contain batteries | No |
| Electrical connection | Cable |
| Electrical connection size | 2 wire |
| Electrical connections terminals | 2-wire cable (2 x 0,2 mm2) |
| Grade of enclosure | IP54 |
| Measuring range [°C] [max] | 100 °C |
| Measuring range [°C] [min] | -50 °C |
| Measuring range [°F] [max] | 212 °F |
| Measuring range [°F] [min] | -58 °F |
| Media temperature [°C] [Max] | 100 °C |
| Media temperature [°C] [Min] | 0 °C |
| Mounting version | Clamp for tube DN 15-65 supplied |
| Packing format | Multi pack |
| Product group | Sensors |
| Product Name Description | Temperature sensor |
| Quantity per packing format | 72 pc |
| REACH Candidate List substances | Lead (CAS no. 7439-92-1) |
| Sensor elem. resistance [Ohm] | 1000 |
| Sensor element [pc] | 1 pc |
| Sensor element standard | EN 60751 |
| Sensor element tolerance | Class B |
| Sensor element type | Pt |
| Temperature sensors type | Pt 1000 |
| Time constant | 10 s |
| Type | ESMC |
| UK RoHS compliance | Out of scope |
| Wires [pcs] | 2 pc |
