| Gross weight | 210 Gram |
| Net weight | 170 Gram |
| Volume | 0.486 Liter |
| EAN | 5715162689448 |
| Gross weight | 210 Gram |
| Net weight | 170 Gram |
| Volume | 0.486 Liter |
| EAN | 5715162689448 |
| Analog inputs (AI) [pc] | 3 pc |
| Application area | Temperature control |
| Approval |
CE CMIM EAC UA UKCA UL |
| CE evaluated | Yes |
| Communication type | MODBUS via. EKA 206 |
| Controller type | Refrig. Controller (Temp) |
| Digital inputs (DI) [pc] | 2 pc |
| Digital outputs (DO) [pc] | 4 pc |
| Display on front | Yes |
| Division | 25 |
| EEE category |
5 small equipment (any external dimension |
| Frequency [Hz] | 50/60 Hz |
| Function | Comp.,Defrost,Fan,Alarm,More f |
| Further information | Alarm= Light or Railheat |
| Identical product | 084B4156 |
| In scope of WEEE | Yes |
| Number of Compressors max. | 1 pc |
| Number of Sensor inputs | 3 pc |
| Packing format | Single pack |
| PFAS content [Yes/No] | No |
| Power consumption [VA] | 0.7 VA |
| Product accessories | Electron. control accessories |
| Product group | Evaporator and room control |
| Product Name Description | Refrig appliance control (TXV) |
| Quantity per packing format | 20 pc |
| REACH Candidate List substances |
Lead (CAS no. 7439-92-1) 6,6'-di-tert-butyl-2,2'-methylenedi-p-cresol (CAS no. 119-47-1) |
| SCIP dossier no. | 2c9550d9-2fd2-41c8-91e9-8b1b0d9c639d |
| SCIP dossier product name | ERC21x, EKC 22x |
| Sensor type | EKS 111, 211, 221, AKS 12, 21 |
| Serviceable | No |
| Supply voltage [V] AC | 230 V |
| Temp. sensor support |
NTC 5000 NTC10000 PTC 990 Pt 1000 |
| Type | EKC 224 |
| UL evaluated | Yes |
| Analog inputs (AI) [pc] | 3 pc |
| Application area | Temperature control |
| Approval |
CE CMIM EAC UA UKCA UL |
| CE evaluated | Yes |
| Communication type | MODBUS via. EKA 206 |
| Controller type | Refrig. Controller (Temp) |
| Digital inputs (DI) [pc] | 2 pc |
| Digital outputs (DO) [pc] | 4 pc |
| Display on front | Yes |
| Division | 25 |
| EEE category |
5 small equipment (any external dimension |
| Frequency [Hz] | 50/60 Hz |
| Function | Comp.,Defrost,Fan,Alarm,More f |
| Further information | Alarm= Light or Railheat |
| Identical product | 084B4156 |
| In scope of WEEE | Yes |
| Number of Compressors max. | 1 pc |
| Number of Sensor inputs | 3 pc |
| Packing format | Single pack |
| PFAS content [Yes/No] | No |
| Power consumption [VA] | 0.7 VA |
| Product accessories | Electron. control accessories |
| Product group | Evaporator and room control |
| Product Name Description | Refrig appliance control (TXV) |
| Quantity per packing format | 20 pc |
| REACH Candidate List substances |
Lead (CAS no. 7439-92-1) 6,6'-di-tert-butyl-2,2'-methylenedi-p-cresol (CAS no. 119-47-1) |
| SCIP dossier no. | 2c9550d9-2fd2-41c8-91e9-8b1b0d9c639d |
| SCIP dossier product name | ERC21x, EKC 22x |
| Sensor type | EKS 111, 211, 221, AKS 12, 21 |
| Serviceable | No |
| Supply voltage [V] AC | 230 V |
| Temp. sensor support |
NTC 5000 NTC10000 PTC 990 Pt 1000 |
| Type | EKC 224 |
| UL evaluated | Yes |
