| Gross weight | 0.352 Kilogram |
| Net weight | 0.246 Kilogram |
| Volume | 2.326 Liter |
| EAN | 5702423284931 |
| Gross weight | 0.352 Kilogram |
| Net weight | 0.246 Kilogram |
| Volume | 2.326 Liter |
| EAN | 5702423284931 |
| Analog inputs (AI) [pc] | 16 pc |
| Analog outputs (AO) [pc] | 6 pc |
| Approval |
CE GOST R |
| Buzzer | Yes |
| CE evaluated | Yes |
| China RoHS compliance | Yes |
| Communication type |
CANBUS MODBUS RS485 |
| Connector kit Code No. | 080G0185 |
| Connector kit included | No |
| Digital inputs (DI) [pc] | 22 pc |
| Digital outputs (DO) [pc] | 20 pc |
| Division | 25 |
| Enclosure rating IP | IP40 |
| EU RoHS compliance | Yes |
| EU RoHS exemption clause | No |
| Frequency [Hz] | 50/60 Hz |
| Function | Programmable Controller |
| Mounting method | DIN rail |
| Packing format | Industrial pack |
| PFAS content [Yes/No] | No |
| Power consumption [W] | 6 W |
| Product accessories | Electron. control accessories |
| Product group | Programmable controllers |
| Product Name Description | Program. controller, 6 relays |
| Quantity per packing format | 24 pc |
| REACH Candidate List substances | No |
| Real time clock | No |
| Serviceable | No |
| Supply voltage [V] AC [max] | 230 V |
| Supply voltage [V] AC [min] | 110 V |
| Type | CSTFR1 |
| Type designation | CSTFR14000070 |
| UK RoHS compliance | Yes |
| Analog inputs (AI) [pc] | 16 pc |
| Analog outputs (AO) [pc] | 6 pc |
| Approval |
CE GOST R |
| Buzzer | Yes |
| CE evaluated | Yes |
| China RoHS compliance | Yes |
| Communication type |
CANBUS MODBUS RS485 |
| Connector kit Code No. | 080G0185 |
| Connector kit included | No |
| Digital inputs (DI) [pc] | 22 pc |
| Digital outputs (DO) [pc] | 20 pc |
| Division | 25 |
| Enclosure rating IP | IP40 |
| EU RoHS compliance | Yes |
| EU RoHS exemption clause | No |
| Frequency [Hz] | 50/60 Hz |
| Function | Programmable Controller |
| Mounting method | DIN rail |
| Packing format | Industrial pack |
| PFAS content [Yes/No] | No |
| Power consumption [W] | 6 W |
| Product accessories | Electron. control accessories |
| Product group | Programmable controllers |
| Product Name Description | Program. controller, 6 relays |
| Quantity per packing format | 24 pc |
| REACH Candidate List substances | No |
| Real time clock | No |
| Serviceable | No |
| Supply voltage [V] AC [max] | 230 V |
| Supply voltage [V] AC [min] | 110 V |
| Type | CSTFR1 |
| Type designation | CSTFR14000070 |
| UK RoHS compliance | Yes |
