| Gross weight | 0.034 Kilogram |
| Net weight | 0.033 Kilogram |
| Volume | 0.025 Liter |
| EAN | 5702425017032 |
| Gross weight | 0.034 Kilogram |
| Net weight | 0.033 Kilogram |
| Volume | 0.025 Liter |
| EAN | 5702425017032 |
| Approval | CE |
| Capacity [kg/h] | 6.55 kg/h |
| Capacity [l/h] | 0 L/h |
| Capacity [USgal/h] | 1.75 gal/h |
| CE evaluated | Yes |
| CEN | Yes |
| China RoHS compliance | Out of scope |
| Contain batteries | No |
| Description | 1.75GAL 45H CEN |
| EU RoHS compliance | Yes with exemptions |
| EU RoHS exemption clause |
6(a) 6(a)-I 6(c) |
| Filter grade [µm] | 75 |
| Filter type | Sinter |
| LE anti-drip valve | No |
| Material type | Brass |
| Packing format | Industrial pack |
| Product group | Oil Nozzles |
| Quantity per packing format | 10 pc |
| REACH Candidate List substances | Lead (CAS no. 7439-92-1) |
| Reference point | 7 bar, 3.4 cSt, 820 kg/m³ |
| SCIP dossier no. | a7055499-33bd-49e7-a364-0e169ee15b9d |
| SCIP dossier product name | 30 H F - Nozzle 0.00-6.00 gph |
| Shape | Conical |
| Specification point | 10 bar, 3.4 cSt, 840 kg/m³ |
| Spray angle [°] | 45 ° |
| Spray pattern | Hollow |
| spray pattern marking | H |
| Type | OD H |
| UK RoHS compliance | Yes with exemptions |
| UK RoHS exemption clause |
12 18 |
| UL evaluated | Out of scope |
| Approval | CE |
| Capacity [kg/h] | 6.55 kg/h |
| Capacity [l/h] | 0 L/h |
| Capacity [USgal/h] | 1.75 gal/h |
| CE evaluated | Yes |
| CEN | Yes |
| China RoHS compliance | Out of scope |
| Contain batteries | No |
| Description | 1.75GAL 45H CEN |
| EU RoHS compliance | Yes with exemptions |
| EU RoHS exemption clause |
6(a) 6(a)-I 6(c) |
| Filter grade [µm] | 75 |
| Filter type | Sinter |
| LE anti-drip valve | No |
| Material type | Brass |
| Packing format | Industrial pack |
| Product group | Oil Nozzles |
| Quantity per packing format | 10 pc |
| REACH Candidate List substances | Lead (CAS no. 7439-92-1) |
| Reference point | 7 bar, 3.4 cSt, 820 kg/m³ |
| SCIP dossier no. | a7055499-33bd-49e7-a364-0e169ee15b9d |
| SCIP dossier product name | 30 H F - Nozzle 0.00-6.00 gph |
| Shape | Conical |
| Specification point | 10 bar, 3.4 cSt, 840 kg/m³ |
| Spray angle [°] | 45 ° |
| Spray pattern | Hollow |
| spray pattern marking | H |
| Type | OD H |
| UK RoHS compliance | Yes with exemptions |
| UK RoHS exemption clause |
12 18 |
| UL evaluated | Out of scope |
