| Gross weight | 1.7 Kilogram |
| Net weight | 1.422 Kilogram |
| Volume | 4.715 Liter |
| EAN | 5702428042789 |
| Gross weight | 1.7 Kilogram |
| Net weight | 1.422 Kilogram |
| Volume | 4.715 Liter |
| EAN | 5702428042789 |
| Ambient temperature range [°C] [max] | 70 °C |
| Ambient temperature range [°C] [min] | -50 °C |
| Ambient temperature range [°F] [max] | 158 °F |
| Ambient temperature range [°F] [min] | -58 °F |
| Approval |
CCC CE EAC LLC CDC EURO-TYSK LVD PZH RMRS RoHS RoHS China TYSK |
| Cap. tube length fraction [in] | 196 7/8 in |
| Capillary tube length [mm] | 5000 mm |
| CE evaluated | Yes |
| China RoHS compliance | Yes |
| Contact differential [°C] | 2 °C |
| Contact function | SPDT |
| Contact rating |
AC15=3 A, 400 V AC1=10 A, 400 V AC3=4 A, 400 V DC13=12 W, 220 V LR=28 A, 400 V |
| Contain batteries | No |
| Diff. temp. setting range [°C] [max] | 15 °C |
| Diff. temp. setting range [°C] [min] | 0 °C |
| Diff. temp. setting range [°F] [max] | 59 °F |
| Diff. temp. setting range [°F] [min] | 0 °F |
| Electrical conn. Male/Female | Female |
| Electrical connection | Screwed cable entry |
| Electrical connection size | 2xPg 13.5 |
| Electrical connection standard | DIN 40430 |
| Electrical spec. standard | EN 60947-4/-5 |
| EN 60947 electrical properties |
Insulation: 400V Pollution degree: 3 Rated impulse voltage: 4 kV Short circuit prot, fuse: 10A |
| EN 60947 wiring properties |
Flex, ferrules: 0.2-1.5 mm2 Flex, no ferrules: 0.2-2.5 mm2 Solid/stranded: 0.2-2.5 mm2 |
| Enclosure rating IP | IP66 |
| EU RoHS compliance | Yes |
| EU RoHS exemption clause | No |
| Max. sensor temperature [°C] | 65 °C |
| Max. sensor temperature [°F] | 149 °F |
| Packing format | Multi pack |
| Pressure connection size | 3/8 |
| Pressure connection standard | ISO 228-1 |
| Pressure connection type | G |
| Pressure Male/Female | Male |
| Product accessories |
Generic accessories Switches accessories |
| Product description | Thermostat |
| Product group | Switches and thermostats |
| Product Name Description | Thermostat |
| Quantity per packing format | 9 pc |
| REACH Candidate List substances | Lead (CAS no. 7439-92-1) |
| Relay release time [s] | 0 s |
| Reset function | Auto |
| SCIP dossier no. | c4c20ce6-4a07-4caa-9394-1e7d8b13ffec |
| Sensor size (Ø x L) [in] | 3/8 x 4 1/4 in |
| Sensor size (Ø x L) [mm] | 9.5 x 110 mm |
| Sensor type | Cylindrical Remote Sensor |
| Serviceable | Contact systems |
| Temperature range [°C] [max] | 40 °C |
| Temperature range [°C] [min] | -30 °C |
| Temperature range [°F] [max] | 105 °F |
| Temperature range [°F] [min] | -20 °F |
| Type | RT270 |
| UK RoHS compliance | Yes |
| Ambient temperature range [°C] [max] | 70 °C |
| Ambient temperature range [°C] [min] | -50 °C |
| Ambient temperature range [°F] [max] | 158 °F |
| Ambient temperature range [°F] [min] | -58 °F |
| Approval |
CCC CE EAC LLC CDC EURO-TYSK LVD PZH RMRS RoHS RoHS China TYSK |
| Cap. tube length fraction [in] | 196 7/8 in |
| Capillary tube length [mm] | 5000 mm |
| CE evaluated | Yes |
| China RoHS compliance | Yes |
| Contact differential [°C] | 2 °C |
| Contact function | SPDT |
| Contact rating |
AC15=3 A, 400 V AC1=10 A, 400 V AC3=4 A, 400 V DC13=12 W, 220 V LR=28 A, 400 V |
| Contain batteries | No |
| Diff. temp. setting range [°C] [max] | 15 °C |
| Diff. temp. setting range [°C] [min] | 0 °C |
| Diff. temp. setting range [°F] [max] | 59 °F |
| Diff. temp. setting range [°F] [min] | 0 °F |
| Electrical conn. Male/Female | Female |
| Electrical connection | Screwed cable entry |
| Electrical connection size | 2xPg 13.5 |
| Electrical connection standard | DIN 40430 |
| Electrical spec. standard | EN 60947-4/-5 |
| EN 60947 electrical properties |
Insulation: 400V Pollution degree: 3 Rated impulse voltage: 4 kV Short circuit prot, fuse: 10A |
| EN 60947 wiring properties |
Flex, ferrules: 0.2-1.5 mm2 Flex, no ferrules: 0.2-2.5 mm2 Solid/stranded: 0.2-2.5 mm2 |
| Enclosure rating IP | IP66 |
| EU RoHS compliance | Yes |
| EU RoHS exemption clause | No |
| Max. sensor temperature [°C] | 65 °C |
| Max. sensor temperature [°F] | 149 °F |
| Packing format | Multi pack |
| Pressure connection size | 3/8 |
| Pressure connection standard | ISO 228-1 |
| Pressure connection type | G |
| Pressure Male/Female | Male |
| Product accessories |
Generic accessories Switches accessories |
| Product description | Thermostat |
| Product group | Switches and thermostats |
| Product Name Description | Thermostat |
| Quantity per packing format | 9 pc |
| REACH Candidate List substances | Lead (CAS no. 7439-92-1) |
| Relay release time [s] | 0 s |
| Reset function | Auto |
| SCIP dossier no. | c4c20ce6-4a07-4caa-9394-1e7d8b13ffec |
| Sensor size (Ø x L) [in] | 3/8 x 4 1/4 in |
| Sensor size (Ø x L) [mm] | 9.5 x 110 mm |
| Sensor type | Cylindrical Remote Sensor |
| Serviceable | Contact systems |
| Temperature range [°C] [max] | 40 °C |
| Temperature range [°C] [min] | -30 °C |
| Temperature range [°F] [max] | 105 °F |
| Temperature range [°F] [min] | -20 °F |
| Type | RT270 |
| UK RoHS compliance | Yes |
